LENOVO IDEAPAD GAMING 3 15ACH6 R5 RTX 2050

• Model: AMD Ryzen™ 5 5600H (5th Gen)
• Architecture: Zen 3 (Cezanne-H)
• Cores/Threads: 6 / 12
• Clock Speeds:
  • Base: 3.3 GHz
  • Boost: Up to 4.2 GHz
  • All-core Boost: Not specified
• Cache:
  • L1: 384 KB
  • L2: 3 MB
  • L3: 16 MB Smart Cache
• TDP: 45W (Standard)
• Performance Benchmarks (Approximate):
  • Cinebench R23: ~1400 (Single) / ~10000 (Multi)
  • Geekbench 5: ~1400 (Single) / ~6500 (Multi)

• Model: NVIDIA® GeForce RTX™ 2050 Laptop GPU (Ampere GA107)
• Processing Units:
  • CUDA Cores: 2048
  • RT Cores: 16 (Gen 2)
  • Tensor Cores: 64 (Gen 3)
• Memory:
  • Capacity: 4GB GDDR6
  • Bus Width: 64-bit
  • Bandwidth: ~112 GB/s
• Clock Speeds:
  • Base: Not specified
  • Boost: Up to ~1500-1635 MHz (Varies with TGP)
• Power:
  • TGP: Up to 70W (Common configuration, may vary by specific model)
  • Dynamic Boost: Included (Amount varies)
• Features:
  • NVIDIA DLSS (Deep Learning Super Sampling)
  • Real-Time Ray Tracing
  • NVIDIA Optimus / MUX Switch (No MUX Switch on most 15ACH6 models)

• Panel Specifications:
  • Size: 15.6-inch
  • Resolution: FHD (1920 x 1080) (~141 PPI)
  • Aspect Ratio: 16:9
  • Type: IPS Level
  • Finish: Anti-glare
• Performance Metrics:
  • Refresh Rate: 120Hz (Common option, 60Hz/165Hz also exist)
  • Response Time: Not specified (Typically ~25ms GtG for budget panels)
  • Adaptive Sync: Supported (Likely FreeSync)
• Color Quality:
  • Brightness: 250 nits (Typical for 120Hz), up to 300 nits on higher refresh panels
  • Color Gamut: 45% NTSC (~60-65% sRGB) – (100% sRGB on 165Hz panels)
  • Delta-E: Not specified (Not factory calibrated)
  • HDR: Not Supported
• Special Features:
  • DC Dimming (On some panels)
  • Narrow Bezels

• Configuration:
  • Capacity: 8GB or 16GB (Typical configurations)
  • Type: DDR4
  • Speed: 3200 MHz
  • Channels: Dual-channel capable
• Upgradability:
  • Slots: 2x SO-DIMM
  • Maximum Supported: Up to 16GB or 32GB (Officially, depending on model)
  • Soldered: No
• Performance Characteristics:
  • Latency: CL22 (Typical for DDR4-3200 SO-DIMM)
  • Bandwidth: ~51.2 GB/s (Theoretical Dual Channel)

• Primary Storage:
  • Type: M.2 NVMe PCIe 3.0 SSD
  • Capacity: 256GB / 512GB (Common configurations)
  • Controller: Varies (e.g., Phison, SK Hynix)
  • NAND Type: TLC or QLC (Varies)
• Performance (Typical 512GB Gen 3):
  • Sequential Read: Up to ~3000 MB/s
  • Sequential Write: Up to ~1500 MB/s
  • Random Read: Not specified
  • Random Write: Not specified
  • Endurance: Varies by model
• Expansion Options:
  • Available Slots: Varies (Often 1x M.2 2242/2280 slot + 1x 2.5″ SATA bay OR 2x M.2 slots – Check specific model)
  • Supported Protocols: PCIe 3.0 NVMe, SATA III
  • Maximum Capacity: Up to 1TB M.2 + 1TB 2.5″ HDD (Model dependent)
• Secondary Storage:
  • Optional 2.5″ HDD/SSD if bay is available and not occupied by second M.2 adapter.

• Technology: Lenovo IdeaPad Gaming Thermal System
• Component Breakdown:
  • Fans: 2x (Improved airflow design compared to non-gaming IdeaPads)
  • Heat Pipes: Multiple copper heat pipes covering CPU & GPU
  • Vapor Chamber: No
  • Exhaust System: Rear and side vents
• Thermal Interface:
  • CPU: Standard Thermal Paste
  • GPU: Standard Thermal Paste
  • VRM: Thermal Pads
• Performance Modes:
  • Quiet: Lower fan speeds, reduced performance
  • Balanced: Automatic adjustment of fans and performance
  • Performance: Higher fan speeds, maximum power limits
  • (Controlled via Lenovo Vantage software or Fn+Q shortcut)
• Smart Features:
  • Q Control (Fn+Q mode switching)

• Keyboard Specifications:
  • Type: Membrane
  • Layout: Full-size with number pad
  • Key Travel: 1.5mm
  • Actuation Force: Not specified
  • Durability: Standard N-key rollover
  • Switch Life: Not specified
• Lighting:
  • Type: White Backlit or optional 4-Zone RGB (Model dependent)
  • Customization: Lenovo Vantage (for RGB models)
  • Effects: Basic effects for RGB models
• Special Features:
  • Anti-ghosting
  • Dedicated Media Keys (via Fn layer)
• Trackpad:
  • Size: ~120 x 70 mm
  • Type: Buttonless Mylar surface, Precision TouchPad
  • Features: Windows Precision drivers, multi-touch gestures

• Battery Specifications:
  • Capacity: 45Wh (Integrated)
  • Chemistry: Li-Polymer
  • Design: Sealed
• Performance (Manufacturer estimates, actual varies):
  • Video Playback: ~5-6 hours
  • Web Browse: ~4-5 hours
  • Gaming: ~1-1.5 hours
  • Idle: Not specified
• Charging:
  • Adapter: 135W Slim Tip (3-pin) AC Adapter
  • Fast Charging: Supports Rapid Charge Pro (Claimed 50% in 30 mins)
  • USB-C PD: Not supported via the USB-C port
• Power Management:
  • Lenovo Vantage battery settings (Conservation mode, etc.)
  • Hybrid Mode (Optimus) switching in Vantage

• Speaker System:
  • Configuration: Stereo speakers
  • Wattage: 2W x 2
  • Positioning: Bottom-firing
• Audio Technologies:
  • Nahimic Audio for Gamers
  • High Definition (HD) Audio, Realtek ALC3287 codec
• Microphone:
  • Type: Dual array microphone
  • Features: Standard noise suppression
  • Position: Near webcam
• Headphone Support:
  • Jack: 3.5mm Headphone / microphone combo jack
  • Output: Standard stereo

• Physical Ports:
  • USB-A: 2x USB 3.2 Gen 1 (5 Gbps)
  • USB-C: 1x USB-C 3.2 Gen 1 (5 Gbps, Data transfer only)
  • Thunderbolt: None
  • HDMI: 1x HDMI 2.0
  • DisplayPort: None (Not via USB-C)
  • Ethernet: 1x RJ-45 (Gigabit Ethernet)
  • Audio: 1x 3.5mm Combo Audio Jack
  • Card Reader: None
  • Power: 1x Lenovo Slim Tip Power Connector
• Wireless:
  • Wi-Fi: Wi-Fi 6 (802.11ax) 2×2
  • Bluetooth: 5.0 or 5.1 (depending on Wi-Fi card)
  • Cellular: None
• Special Connections:
  • None

• Materials:
  • Top Cover: PC + ABS Plastic
  • Base: PC + ABS Plastic
  • Internal Frame: Plastic
• Dimensions:
  • Height: 24.2 mm (0.95 inches)
  • Width: 359.6 mm (14.16 inches)
  • Depth: 251.9 mm (9.92 inches)
  • Weight: Starting at 2.25 kg (4.96 lbs)
• Durability:
  • Certifications: None specified (Not MIL-STD tested)
  • Keyboard: Standard
  • Hinge: Standard laptop hinge
• Aesthetics:
  • Color Options: Shadow Black
  • Lighting: Keyboard backlight (White or RGB)
  • Branding: Lenovo logo on lid and palm rest, IdeaPad Gaming branding

• Operating System:
  • Primary: Windows 11 Home (Typical)
  • Alternatives: Windows 11 Pro (Optional), No OS (Optional)
  • Recovery: Windows standard recovery partition
• Security Features:
  • Hardware: Firmware TPM 2.0 (fTPM) integrated in CPU
  • Biometrics: None
  • Physical: Kensington Nano Security Slot™ (Check specific model), Webcam privacy shutter
• Enterprise Management:
  • vPro: No
  • Management Software: Standard Windows management
  • Deployment: Standard Windows methods
• Privacy Features:
  • Webcam: Physical privacy shutter
  • Microphone: Software mute

• Pre-installed Software:
  • Productivity: Microsoft Office Trial (Often included)
  • Utilities: Lenovo Vantage, Nahimic Audio
  • Trial Software: McAfee LiveSafe™
• Control Center:
  • Name: Lenovo Vantage
  • Features: System updates, hardware settings, performance modes, battery settings, network boost, lighting control (RGB models)
• Driver Support:
  • Update Method: Lenovo Vantage, Lenovo Support Website, Windows Update
  • Support Duration: Typically several years post-launch

The IdeaPad Gaming 3 15ACH6 (R5/RTX 2050) offers a compelling value proposition in the entry-level gaming segment. It balances a capable Ryzen 5 CPU with an RTX-enabled GPU, making it suitable for 1080p gaming, particularly in esports titles and older AAA games, enhanced by DLSS support.

Ideal for:

• Budget gamers wanting access to RTX features like DLSS.
• Students or users needing a laptop for both work/study and casual gaming.
• Users prioritizing CPU performance alongside moderate gaming capabilities.
• Gamers playing less demanding titles or willing to adjust settings in modern games.

Consider alternatives if:

• You need higher peak gaming performance (Look for laptops with RTX 3050/4050 or higher TGP GPUs).
• Color accuracy and display brightness are critical (Consider models with 100% sRGB screens).
• You require premium build materials or longer battery life (Ultrabooks or higher-tier gaming laptops).
• You need USB-C display output or charging (Look for models with full-featured USB-C/Thunderbolt).

Final Recommendation: A solid starting point for gaming on a budget. It delivers respectable performance and features for its price class, especially if found with the 120Hz or 165Hz display. Be mindful of the compromises, particularly the base display quality and plastic construction, but its upgradability adds long-term value.
