MSI KATANA GF66 12UD i7 + RTX 3050TI

• Model: Intel Core i7-12650H (Alder Lake)
• Architecture: Hybrid (6P+4E cores)
• Cores/Threads: 10 (6P+4E) / 16
• Clock Speeds:
  • Base: 2.3 GHz (P-core) / 1.7 GHz (E-core)
  • Boost: Up to 4.7 GHz (P-core)
  • All-core Boost: Up to 4.1 GHz
• Cache:
  • L1: 80KB (P-core) / 96KB (E-core)
  • L2: 1.25MB (P-core) / 2MB (E-core)
  • L3: 24MB Smart Cache
• TDP: 45W (Base), 115W (Max Turbo Power)
• Performance: Cinebench R23: ~1,750 (Single), ~12,800 (Multi)

• Model: NVIDIA GeForce RTX 3050 Ti Laptop GPU
• Architecture: Ampere (GA107)
• CUDA Cores: 2,560
• RT Cores: 20 (2nd Gen)
• Tensor Cores: 80 (3rd Gen)
• Memory:
  • Capacity: 4GB GDDR6
  • Bus Width: 128-bit
  • Bandwidth: 224 GB/s
• Clock Speeds:
  • Base: 1,035 MHz
  • Boost: Up to 1,485 MHz (1,695 MHz with Dynamic Boost)
• TGP: 75W (95W with Dynamic Boost)
• Performance:
  • 3DMark Time Spy: ~5,800 Graphics Score
  • 1080p Gaming: 60+ FPS in esports, 40-60 FPS in AAA titles (medium settings)
• Features: DLSS, Ray Tracing, NVIDIA Reflex, WhisperMode 2.0

• Panel Specifications:
  • Size: 15.6-inch Full HD (1920×1080)
  • Type: IPS-level
  • Refresh Rate: 144Hz
  • Response Time: 3ms (GtG)
  • Finish: Matte anti-glare
• Color Quality:
  • Brightness: 250 nits
  • Color Gamut: 45% NTSC (~60% sRGB)
  • Contrast Ratio: 1000:1
• Special Features:
  • MSI Anti-Flicker Technology
  • Less Blue Light (TÜV certified)

• Configuration:
  • Capacity: 16GB DDR4 (2×8GB)
  • Speed: 3,200 MHz
  • Channels: Dual-channel
• Upgradability:
  • Slots: 2x SO-DIMM
  • Maximum Supported: 64GB (32GB per slot)

• Primary Storage:
  • Type: 512GB NVMe PCIe 3.0 SSD
  • Sequential Read: Up to 3,500 MB/s
  • Sequential Write: Up to 2,300 MB/s
• Expansion Options:
  • 1x M.2 PCIe 3.0 slot (occupied)
  • 1x 2.5″ SATA bay (empty)

• Cooling System:
  • Fans: 2x (shared heatsink for CPU+GPU)
  • Heat Pipes: 6x (copper, 3.5mm diameter)
• Performance Modes:
  • Silent: Reduced fan noise (35dB)
  • Balanced: Optimal performance/noise (45dB)
  • Extreme: Maximum cooling (55dB)

• Type: Membrane gaming keyboard
• Key Travel: 1.7mm
• Lighting: Per-key RGB (16.8M colors)
• Special Features:
  • Anti-ghosting technology
  • Dedicated numpad
  • WASD key highlights

• Battery:
  • Capacity: 53.5Wh
  • Chemistry: 3-cell Li-ion
• Performance:
  • Gaming: ~1.5 hours
  • Video Playback: ~5 hours
  • Web Browsing: ~4 hours
• Power Adapter:
  • Capacity: 180W (19.5V/9.23A)
  • Weight: 550g

• Ports:
  • 1x USB 3.2 Gen2 Type-C (DP/PD)
  • 2x USB 3.2 Gen1 Type-A
  • 1x USB 2.0 Type-A
  • 1x HDMI 2.1 (4K@60Hz)
  • 1x RJ-45 Ethernet (Gigabit)
  • 1x Audio combo jack
• Wireless:
  • Wi-Fi 6 (Intel AX201, 2×2)
  • Bluetooth 5.2
• Webcam: HD (720p) with privacy shutter

• Materials:
  • Top Cover: Brushed aluminum
  • Palm Rest: Plastic with textured finish
• Dimensions:
  • Height: 24.9mm (0.98″)
  • Width: 359mm (14.13″)
  • Depth: 259mm (10.2″)
  • Weight: 2.25kg (4.96 lbs)
• Design Elements:
  • Angular chassis with red accents
  • MSI Dragon logo on lid

The MSI Katana GF66 12UD delivers excellent 1080p gaming performance at a mid-range price point, combining Intel’s 12th Gen i7 processor with NVIDIA’s RTX 3050 Ti in a relatively portable package.

Ideal for:

• Gamers who want smooth 1080p gameplay in esports and AAA titles
• Content creators needing GPU acceleration for light video editing
• Students who want both gaming and productivity in one machine

Consider alternatives if:

• You need higher refresh rates (look for 240Hz+ displays)
• You want to play at QHD resolution (consider RTX 3060+ models)
• You prioritize battery life over performance

Final Recommendation: The MSI Katana GF66 12UD offers great value for gamers on a budget, providing solid performance and features typically found in more expensive laptops, though with some compromises in display brightness and battery life.
